NSK BEARINGS various selection , welcome inquiry online or email me directly to : info@cmtgbearing.com.
| Bearing Numbers | Abutment and Fillet Dimensions (mm) da Db ra max . | rb max . | Constant e |
2 | Axial Load Factors 3 |
0 | Mass (kg) approx . | ||
| * EE971354 / 972102D+L | 390 | 510 | 4.8 | 1.5 | 0.33 | 3.0 | 2.0 | 2.0 | 116 |
| * EE971354 / 972103D+L | 390 | 510 | 4.8 | 1.5 | 0.33 | 3.0 | 2.0 | 2.0 | 121 |
| * EE971354 / 972151D+L | 390 | 517 | 4.8 | 3.3 | 0.33 | 3.0 | 2.0 | 2.0 | 141 |
| * EE161363 / 161901D+L | 385 | 465 | 7.0 | 1.5 | 0.50 | 2.0 | 1.4 | 1.3 | 64.8 |
| * HM262749 / HM262710D+L | 386 | 475 | 6.4 | 1.5 | 0.33 | 3.0 | 2.0 | 2.0 | 109 |
| * EE333137 / 333203D+L | 394 | 495 | 6.4 | 1.5 | 0.37 | 2.7 | 1.8 | 1.8 | 130 |
| 355KBE5101+L | 397 | 495 | 6.4 | 1.5 | 0.37 | 2.7 | 1.8 | 1.8 | 126 |
| * L163149 / L163110D+L | 381 | 435 | 3.5 | 1.5 | 0.31 | 3.3 | 2.2 | 2.1 | 44.7 |
| * EE161400 / 161901D+L | 390 | 465 | 7.0 | 1.5 | 0.50 | 2.0 | 1.4 | 1.3 | 59.3 |
| * EE231400 / 231976D+L | 403 | 489 | 6.4 | 1.5 | 0.44 | 2.3 | 1.5 | 1.5 | 85.8 |
| * EE333140 / 333203D+L | 397 | 495 | 6.4 | 1.5 | 0.37 | 2.7 | 1.8 | 1.8 | 125 |
| 360KBE30 + L | 405 | 522 | 5 | 2 | 0.39 | 2.6 | 1.7 | 1.7 | 97.6 |
| 360KBE030 + L | 409 | 524 | 5 | 2 | 0.39 | 2.6 | 1.7 | 1.7 | 123 |
| 360KBE5601A +L | 410 | 540 | 4 | 2 | 0.28 | 3.6 | 2.4 | 2.4 | 254 |
| 360KBE31 + L | 420 | 577 | 5 | 2 | 0.41 | 2.4 | 1.6 | 1.6 | 214 |
| 360KBE031 + L | 420 | 577 | 5 | 2 | 0.39 | 2.6 | 1.7 | 1.7 | 260 |
| 360KBE6001 +L | 420 | 579 | 5 | 2 | 0.41 | 2.4 | 1.6 | 1.6 | 220 |
| * EE181453 / 182351D+L | 428 | 570 | 9.7 | 2.3 | 0.41 | 2.4 | 1.6 | 1.6 | 196 |
