NACHI Tapered Roller Bearings 359S

NACHI Tapered Roller Bearings

Boundary dimensions(mm)							Bearing No.
d	D	T	B	C	r1 (min)	2 (min)	Cone	Cup
46.038	79.375	17.463	17.463	13.495	2.80	1.60	18690	18620
	85.001	20.638	21.692	17.463	2.40	1.30	359S	354A
47.625	88.900	20.638	22.225	16.513	2.40	1.30	369S	362A
	88.900	25.400	25.400	19.050	3.60	3.20	M804049	M804010
	90.000	20.000	22.225	15.875	3.60	2.00	369A	362
	93.264	30.163	30.302	23.813	3.60	3.20	3779	3720
	95.250	30.163	29.370	23.020	3.60	3.20	HM804846	HM804810
	107.950	36.513	36.957	28.575	3.60	3.20	536	532X
48.412	95.250	30.163	29.370	23.020	2.40	3.20	HM804848	HM804810
49.213	104.775	36.513	36.513	28.575	3.60	3.20	HM807044	HM807010
50.000	82.000	21.500	21.500	17.000	3.00	0.50	H-JLM104948	H-JLM104910
	84.000	22.000	22.000	17.500	3.50	1.50	H-JLM704649	H-JLM704610
	90.000	28.000	28.000	23.000	3.00	2.50	JM205149	JM205110
	105.000	37.000	36.000	29.000	3.00	2.50	JHM807045E	JHM807012E
50.800	82.550	21.590	22.225	16.510	3.60	1.20	H-LM104949	H-LM104911
	82.931	21.590	22.225	16.510	3.60	1.20	H-LM104949	H-LM104912
	85.001	17.463	17.463	13.495	3.60	1.60	18790	18720
	88.900	20.638	22.225	16.513	3.60	1.30	368A	362A
	89.980	24.750	25.400	19.987	3.60	2.40	28580R	28520
	90.000	20.000	22.225	15.875	3.60	2.00	368A	362
	92.075	24.608	25.400	19.845	3.60	0.80	28580R.	28521
	93.264	30.163	30.302	23.813	0.80	3.20	3775	3720
	93.264	30.163	30.302	23.813	3.60	3.20	3780	3720
	95.250	27.783	28.575	22.225	3.60	2.40	33889	33821
	95.250	27.783	28.575	22.225	3.60	0.80	33889	33822
	97.630	24.608	24.608	19.446	3.60	0.80	28678	28622
	101.600	31.750	31.750	25.400	3.60	3.20	49585	49520
	101.600	34.925	36.068	26.988	0.80	3.20	529	522
	101.600	34.925	36.068	26.988	3.60	3.20	529X	522
	104.775	30.163	30.958	23.813	6.40	3.20	45284	45220
	104.775	36.513 36.513	36.513	28.575	3.60	3.20	HM807046	HM807010
	107.950		36.957	28.575	3.60	3.20	537	532X
51.592	90.000	20.000	22.225	15.875	2.00	2.00	368S	362
