Boundary dimensions (mm) | Basicย loadย ratings (kN) Caย ย ย ย ย ย ย ย ย ย ย ย ย ย ย C0a | Fatigue loadย limit (kN) Cu | Bearingย No. | De-ย ย ย sign | Dimensions (mm) d1ย ย ย ย ย ย ย ย ย ย ย ย ย ย ย ย D1 max.ย ย ย ย ย ย ย ย min. | Mounting dimensions (mm) | (Refer.) Mass (kg) | ||||||||
d ย ย ย ย ย ย Dย ย ย ย ย ย ย T | r min. | da min. | Da max. | ra max. | |||||||||||
320 | 440 | 95 | 3 | 721 | 2 | 710 | 62.9 | 51264 | 2 | 435 | 325 | 391 | 369 | 2.5 | 45.0 |
340 | 420 | 64 | 2 | 483 | 1 | 860 | 43.1 | 51168 | 2 | 416 | 344 | 388 | 372 | 2 | 20.5 |
460 | 96 | 3 | 730 | 2 | 830 | 63.8 | 51268 | 2 | 455 | 345 | 411 | 389 | 2.5 | 48.0 | |
360 | 440 | 65 | 2 | 493 | 1 | 960 | 44.3 | 51172 | 2 | 436 | 364 | 408 | 392 | 2 | 21.5 |
500 | 110 | 4 | 876 | 3 | 500 | 76.1 | 51272 | 2 | 495 | 365 | 443 | 417 | 3 | 70.0 | |
380 | 460 | 65 | 2 | 494 | 2 | 010 | 44.3 | 51176 | 2 | 456 | 384 | 428 | 412 | 2 | 23.0 |
520 | 112 | 4 | 889 | 3 | 650 | 77.8 | 51276 | 2 | 515 | 385 | 463 | 437 | 3 | 74.0 | |
400 | 480 | 65 | 2 | 503 | 2 | 110 | 45.4 | 51180 | 2 | 476 | 404 | 448 | 432 | 2 | 24.0 |
540 | 112 | 4 | 903 | 3 | 810 | 79.4 | 51280 | 2 | 535 | 405 | 483 | 457 | 3 | 78.0 | |
420 | 500 | 65 | 2 | 512 | 2 | 210 | 46.6 | 51184 | 2 | 495 | 424 | 468 | 452 | 2 | 25.0 |
580 | 130 | 5 | 1ย 020 | 4 | 420 | 89.4 | 51284 | 2 | 575 | 425 | 515 | 485 | 4 | 111 | |
440 | 540 | 80 | 2.1 | 652 | 2 | 930 | 59.7 | 51188 | 2 | 535 | 444 | 499 | 481 | 2 | 41.5 |
600 | 130 | 5 | 1ย 040 | 4 | 620 | 91.6 | 51288 | 2 | 595 | 445 | 535 | 505 | 4 | 115 | |
460 | 560 | 80 | 2.1 | 633 | 2 | 850 | 57.1 | 51192 | 2 | 555 | 464 | 519 | 501 | 2 | 43.0 |
620 | 130 | 5 | 1ย 060 | 4 | 830 | 93.8 | 51292 | 2 | 615 | 465 | 555 | 525 | 4 | 120 | |
480 | 580 | 80 | 2.1 | 570 | 2 | 610 | 51.1 | 51196 | 2 | 575 | 484 | 539 | 521 | 2 | 44.0 |
500 | 600 | 80 | 2.1 | 683 | 3 | 300 | 63.6 | 511/500 | 2 | 595 | 505 | 559 | 541 | 2 | 46.0 |
530 | 640 | 85 | 3 | 729 | 3 | 570 | 66.8 | 511/530 | 2 | 635 | 535 | 595 | 575 | 2.5 | 57.5 |
CMTG BEARING CO.,LIMITED. ย has been engaged in bearing industry for many years, we provide a wide selections of brands, includingย FAG bearing,ย SKF bearing,NSKย bearing,Nachi bearing, TIMKEN bearing, THK Linear Guide and Linear Block โฆect.
Bearing typies including standard bearing and non-standard bearings, linear bearings, automotive bearings, large bearings, railway bearings,spherical plain bearings, high temperature,super-precision bearings, as well as some rare types customized to your need.
Contact us if any bearing in demand . we will check and revert ASAP.
